Desktop mill-DM3

Desktop mill-DM3

● Mitsubishi controller

● Suitable for school projects and factory training

● Real milling, tapping and drawing function

● Testing tools

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Desktop mill-DM3

Specification

Machine Type
Desktop mill-DM3
Control unit
M80
Travel X-axis travel 125 / 300 mm
Y-axis travel 110 / 250 mm
Z-axis travel 130 / 225 mm
Spindle Spindle nose to table 200mm
Type of spindle ER-25
Spindle transmission Direct drive
Spindle R.P.M. 3000/5000 RPM
Spindle motor 1.5Kw
Feedrate X/Y/Z rapid traverse 20/20/20 M/min
Three axes ball screws(mm) 25mm / P5 / C5
Three axes linear guide(P class) Ball Type 25mm x 4 Blocks
Three axes transmission method Direct drive
Cutting feed rate 1-5,000mm/min
Table Table size (mm) 400x200
T-slot ( W x No. x Pitch) 14x4x55mm
Table loading capacity 100kg
Machine size Machine size ( LxWxH)(mm) 750x650x850mm
Desk size 1200x650x700
Max. machine weight 550Kg
